rMQR codes

The rMQR Code for "Padonma"

rMQR Codes

Critical to the Padonma Network is the relatively new QR variant, rMQR, which became an ISO standard in May of 2022. An apropos analogy would be: QR is to square as rMQR is to rectangle. Traditional QRs are all square shaped. The 21 module size QR is the minimum size QR that can contain the 16 bytes of a UUID. On the other hand a rMQR can be as narrow as 7. Handpicking warp threads to make a black versus white module is a lot easier around 7 at a go versus 21 per weaving pass.

Padonma’s free rMQR software

As of late 2026, both iOS and Android default camera apps cannot recognize rMQR Codes dispite ISO publishing the rMQR standard in 2022. Nonetheless, there are free apps for both platforms (for example, the app QRQR) that can scan rMQR Codes.

One of the things that the Padonma Network has produced is free open source code for web pages that read and write rMQRs with UUIDs in them.

The webpage is packaged as a PWA which means the page can work offline, say, in the middle of the jungle of Burma during a civil war which does not help with network coverage.

It is on the roadmap to package the software via Capacitor which is simply a way to wrap a webpage into an iOS and/or Android native app. For now the PWS is sufficient to work in the jungle. Having native apps would simply make it easier to discover in apps stores. Sure why not? Once development settles through usage testing.

UUIDs inside rMQR Codes

An R7-sized rMQR is – as the name implies – 7 modules (“pixels”) tall. Here is what an example R7x77 rMQR looks like.

This is the smallest rMQR Code which is large enough to encode a UUID, which would be a very useful garment ID by which Padonma could track garments in a distributed inventory system.

(Note the rMQR spec calls for a two module wide margin “quiet zone” around an rMQR Code, so the white background margin has to be accounted for when weaving a rMQR Code. More importantly, a R7-sized rMQR would require an 11 module wide band to be handwoven, although those 4 extra modules do not require handpicking so they are easier to weave. Note that the rMQR specs considers the narrow dimension to be height, while from the weavers perspective – potentially confusingly – the narrow dimension is the width of the band.)

All Universally Unique Idenfifiers (UUIDs) are 128 bits long or, in other words, 16 bytes in size. According to ISO 23941, an rMQR Code of size R7x77 at error correction level “M” can handle a maximum byte-mode payload 160 bits (or 19 bytes max). Or an R9x77 (error correction “H”) can also handle exactly 16 bytes of data.

For Padonma, the QR code will contain a UUID that IDs the garment. For example, one of those UUIDs might look like the following:

170bf486-a96f-47e9-90e6-632373d27924

Development history of rMQR Codes

QR Codes were first open sourced by DENSO (Toyota Group) in 1994. From the begining, QR Codes have always been squares, orignally size 21 to 73. In 2000, the QR spec work was transfered to the ISO/IEC standards bodys which published the QR Code standard as 18004, with square size extended from a max of 73 to 177. Over the years that spec has been updated (the latest being 2024) yet those QR Codes are always remained squares, now sized 11 to 177.

rMQR was also invented by DENSO and in 2022 ISO/IEC pusblished the rMQR standard as 23941. It was this standard that defines the first standard non-square QR codes.

In May of 2022, ISO standardized a new QR code variant. Standard ISO/IEC 23941 defines this new type of QR code, called rMQR codes. They are designed to be narrow (7 to 17 “modules” wide), and come in various lengths as needed to address data storage requirements.

Six blank rMQR codes of various sizes
